3 seats
Standard
|
PARAMETERS |
|
|
|
|---|---|---|---|
|
Number of seats |
2+1 |
2+1 |
2+1 |
| Passenger capacity | 2 | 2 | 2 |
|
Engine type |
- |
ISF2.8s4129P |
EVOTECH A274 |
|
Axle configuration |
4x2/4×4 |
4x2/4×4 |
4x2/4×4 |
|
Drive type |
Rear |
Rear |
Rear |
|
GVW, kg |
2800/3000 |
2800/3000 |
2800/3000 |
|
Curb weight, kg |
1805/1945 |
1875/2095 |
1805/1945
|
|
Distribution of road load of GVW vehicle through tires, kg Front wheels Rear wheels |
1250/1400 1550/1600 |
1370/1520 1430/1480 |
1250/1400 1550/1600 |
|
Wheelbase, mm |
2760 |
2760 |
2760 |
|
Wheel tread Front, mm Rear, mm (between the centers of double tires) |
1700/1720 1700 |
1700/1720 1700 |
1700/1720 1700 |
|
Clearance (below the rear axle housing @ GVW), mm |
205 |
205 |
205 |
|
Minimum turning radius by the outside front wheel tread, m |
5,5/6 |
5,5/6 |
5,5/6 |
|
Maximum speed on a horizontal smooth highway, km/h |
130/120 |
150/115 |
130/120 |
|
Overhang angles (under load) Front, degrees Rear, degrees |
22/29 28/32 |
22/29 28/32 |
22/29 28/32 |
|
Maximum uphill gradient using the main fuel type under full load, % |
29/30 |
29/30 |
29/30 |
|
Loading height, mm |
900/1000 |
900/1000 |
900/1000 |
|
Internal body dimensions, mm Length Width Height |
2339 1978 400 |
2339 1978 400 |
2339 1978 400 |
|
Gearbox |
5-speed, manual |
5-speed, manual |
5-speed, manual |
|
Fuel tank capacity, l |
64 |
64 |
64 |
* 231000
** 231000-0000344
All the technical specifications are given for reference, please ask the official dealer in your region for detailed information according to the vehicle-type approval.
