GAZELLE NEXT VAN

Full specifications

3 seats Standard 2+1

2 513^mm

2 753^mm

2 068^mm

5 607^mm

3 145^mm

3 seats Long2+1

2 513^mm

2 753^mm

2 068^mm

6 207^mm

3 745^mm

3 seats Extra Long 2+1

2 513^mm

2 775^mm

2 068^mm

6 907^mm

3 950^mm

7 seats Standard 6+1

2 513^mm

2 753^mm

2 068^mm

5 607^mm

3 145^mm

7 seats Long 6+1

2 513^mm

2 753^mm

2 068^mm

6 207^mm

3 745^mm

7 seats Extra Long 6+1

2 513^mm

2 775^mm

2 068^mm

6 907^mm

3 950^mm

3 seats
Standard
2+1

3 seats Standard 2+1

3 seats
Standard
2+1

3 seats Long2+1

3 seats
Long
2+1

3 seats Extra Long 2+1

3 seats
Extra Long
2+1

7 seats Standard 6+1

7 seats
Standard
6+1

7 seats Long 6+1

7 seats
Long
6+1

7 seats Extra Long 6+1

7 seats
Extra Long
6+1

Models

PARAMETERS	Standard Single cab/ double cab	Long Single cab/ double cab	Long Single cab/ double cab	Extra long Single cab/ double cab
Cargo compartment volume, m³	11.5 / 7.5	13.5 / 9.5	13.5 / 9.5	15.5 / 11.5
Number of seats	3 / 7	3/ 7	3 / 7	3 / 7
Wheel arrangement	4×2	4×2	4×2	4×2
Driving axle	Rear	Rear	Rear	Rear
GVW, kg	3500	3500	4600	4600
Curb weight, kg	2470 / 2585	2565 / 2680	2380 / 2480	2785 / 2910
Wheelbase, mm	3145	3745	3745	3950
Clearance, mm	170	170	170	170
Minimum turning radius by the outside front wheel tread, m	5,7	6,5	7,2	7,2
Maximum speed, km/h	130	130	130	130
Maximum driving gradient of a fully loaded vehicle, %	26	26	26	26
Loading height, mm	730	730	730	765
Internal body dimensions, mm Length Width Height	2400 / 3031 1860 1927	3631 / 3000 1860 1927	3631 / 3000 1860 2040	4331 / 3700 1860 2040
Gearbox type, number of speeds	Manual, 5-speed	Manual, 5-speed	Manual, 5-speed	Manual, 5-speed
Fuel tank capacity, l	80	80	80	80
