19 seats
Citiline
18+1
|
PARAMETERS |
|
|
|
|---|---|---|---|
|
Number of seats |
18 |
18+1 |
|
| Passenger capacity | 18 | 19 | |
|
Axle configuration |
4×2 |
4×2 |
|
|
Drive type |
Rear |
Rear |
|
|
GVW, kg*** |
4183 |
4145 |
|
|
Curb weight, kg*** |
2905 |
2853 |
|
|
Distribution of road load of GVW vehicle through tires, kg*** Front wheels Rear wheels |
1348
2835 |
1339
2806 |
|
|
Wheelbase, mm |
3745 |
3745 |
|
|
Front wheel tread, mm |
1750 |
1750 |
|
|
Rear wheel tread (between the centers of double tires), mm |
1560 |
1560 |
|
|
Clearance (below the rear axle housing @ GVW), mm |
170 |
170 |
|
|
Minimum turning radius by the outside front wheel tread, m |
6,5 |
6,5 |
|
|
Maximum speed on a horizontal smooth highway, km/h |
130 |
130 |
|
|
Overhang angles (under load)*** Front, degrees Rear, degrees |
22 14 |
22 14 |
|
|
Maximum uphill gradient using the main fuel type under full load, %*** |
26 |
26 |
|
|
Gearbox |
Manual, 5-speed |
Manual, 5-speed |
|
|
Fuel tank capacity, l |
80 |
80 |
* A65R33-61
** A263R42-10/A64R42-10
*** These parameters are different for each engine.
All the technical specifications are given for reference, please ask the official GAZ dealer in your region for detailed information according to the vehicle-type approval.
