PARAMETERS |
|
|
![]() Standard platform |
![]() Standard platform |
![]() Standard platform |
---|---|---|---|---|---|
Number of seats |
8+1 |
8+1 |
12+1 | 13+1 | 13+1 |
Passenger capacity | 8 | 8 | 12 | 13 | 13 |
Axle configuration |
4×2 |
4×4 |
4×2 | 4×2 | 4×4 |
Drive type |
Rear |
Rear |
Rear | Rear | Rear |
GVW, kg |
3165 |
3350 |
3470 | 3525 | 3660 |
Curb weight, kg*** |
2475 |
2650 |
2500 | 2480 | 2610 |
Distribution of road load of GVW vehicle through tires, kg*** Front wheels Rear wheels |
1970 |
2030 |
2120 |
2205 |
2225 |
Wheelbase, mm |
2900 |
2900 |
2900 | 2900 | 2900 |
Wheel tread: Front, mm Rear (between the centers of double tires), mm |
1560 |
1560 |
1560 |
1560 |
1560 |
Clearance (below the rear axle housing @ GVW), mm |
170 |
190 |
170 | 170 | 190 |
Minimum turning radius by the outside front wheel tread, m |
5.5 |
7.5 |
5.5 | 5.5 | 7.5 |
Maximum speed on a horizontal smooth highway, km/h*** |
130 |
120 |
130 | 130 | 120 |
Overhang angles (under load) Front, degrees Rear, degrees |
22 17 |
29 19 |
22 11 |
22 11 |
29 19 |
Maximum uphill gradient using the main fuel type under full load, % |
26 |
30 |
26 | 26 | 30 |
Gearbox |
5-speed, manual |
5-speed, manual |
5-speed, manual | 5-speed, manual | 5-speed, manual |
Fuel tank capacity, l |
80 |
80 |
80 | 80 | 80 |
